Epauto 30/40 Amp Relay Harness Spdt 12V Bosch Style – 4 Pack

Contact Capacity:

Normal Switching Capacity (Res.Load):
– No 40A 14Vdc
– Nc 30A 14Vdc
Max. Switching Current: 40A
Max. Switching Voltage: 30Vdc
Max. Switching Power: 560W

Characteristic Data:

Initial Contact Resistance (At 6Vdc 1A): 50M? Max.
Operate Time (At Nominal Volt.): 10 Msec. Max.
Release Time (At Nominal Volt.): 5 Msec Max.
Initial Insulation Resistance: 100M? Min. (Dc500V)
Initial Dielectric Strength:
– Between Open Contacts: Ac500V, 50/60 Hz 1Min.
– Between Coil And Contact: Ac500V, 50/60 Hz 1Min.
Vibration Resistance:
– Functional: 10 ~ 55Hz At Double Amplitude Of 1.5 Mm
– Destructive: 10 ~ 55Hz At Double Amplitude Of 1.5 Mm
Shock Resistance:
– Functional: 20G Min.
– Destructive: 100G Min.
Endurance (Operations):
– Mechanical (At 7,200 Ops./H): 10,000,000
– Electrical (At 600 Ops./H): 100,000
Ambient Temperature: -40°C ~ +125°C (No Condensation)
